REFRIGERANT CYLINDERS (REFILLABLE AND DISPOSABLE)

REFRIGERANT CYLINDERS (REFILLABLE AND DISPOSABLE)

Brand: KAIGEN and LEO

I. Disposable Refrigerant Cylinders

(I) Ordinary disposable refrigerant cylinders

High-quality materials, production attention to details, delicate and smooth cylinder body, comfortable and natural cylinder body, high-end atmosphere.

Capacity: 15 LB, 24 LB, 25 LB, 30 LB, 50 LB, 1 L, 3.5 L, 4.5 L, 5 L, 6.7 L, 6.8 L, 7 L, 7.1 L, 13 L, 13.3 L, 13.4 L, 22 L, 22.3 L, 22.4 L, 22.7 L, etc.

Working pressure: 260 Psi, 276 Psi, 320 Psi, 325 Psi, 400 Psi, 417 Psi, 452 Psi; 1.79 MPa, 1.8 MPa, 1.84 MPa, 1.9 MPa, 2.1 MPa, 2.16 MPa, 2.2 MPa, 2.22 MPa, 2.24 MPa, 2.3 MPa, 2.7 MPa, 2.75 MPa, 2.76 MPa, 2.84 MPa, 3 MPa, 3.04 MPa, 3.08 MPa, 3.11 MPa, 3.12 MPa; 15 Bar, 18 Bar, 23 Bar, 24 Bar, 27 Bar, 28 Bar, 30 Bar, 34.5 Bar, 42 Bar, 45 Bar, etc.

Standard and Certification: DOT, KGS, KHK, EN, EN ISO, ROHS, BSCI, FSC, GB, etc.

(II) Mini disposable refrigerant cylinder

Small cylinder, simple appearance, easy to operate.

Capacity: 1 L, etc.

Wall Thickness: 0.8 mm, 1.00 mm, etc.

Working pressure: 260 Psi, 417 Psi, 15 Bar, 24 Bar, etc.

(III) Disposable cylinder for automotive refrigerant

Designed for automotive refrigerant, it has a beautiful and smooth appearance, convenient operation and easy use.

Capacity: 300 ml, 340 ml, 450 ml, 500 ml, 1000 ml, etc.

Wall Thickness: 0.36 mm, etc.

Working pressure: 1.8 MPa, 2.0 MPa, etc.

II. Refillable Refrigerant Cylinders

Each cylinder undergoes rigorous quality inspection to ensure product safety and reliability.

Capacity: 10 L, 12 L, 12.2 L, 12.3 L, 13.6 L, 14 L, 18 L, 20 L, 22.4 L, 28 L, 35.5 L, 40 L, 50 L, 58 L, 60 L, 68 L, 70 L, 72 L, 80 L, 82 L, 90 L, 100 L, 105 L, 107 L, 118 L, 120 L, 130 L, 150 L, 200 L, 360 L, 400 L, 450 L, 453 L, 500 L, 800 L, 840 L, 926 L, 930 L, 944 L, 980 L, 1000 L, etc.

Working pressure: 24 Bar, 32 Bar, 47 Bar, 48 Bar, 64 Bar, 1 MPa, 1.9 MPa, 2 MPa, 2.1 MPa, 2.2 MPa, 2.5 MPa, 3 MPa, 4 MPa, 12.5 MPa, etc.

Diameter: 217 mm, 228 mm, 236 mm, 238 mm, 250 mm, 300 mm, 314 mm, 350 mm, 400 mm, 600 mm, 800 mm, 850 mm, 900 mm, etc.

Material: S31603, HP295, HP325, HP345, Q345, 16MnR, SUS304, S304, S316, SG295, SG325, etc.

Wall Thickness: 2.5 mm, 2.6 mm, 3 mm, 3.6 mm, 4 mm, 4.5 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm, 14 mm, 16 mm, 25 mm, etc.

Standard and Certification: ASME, DOT, TPED, CE, KGS, KHK, EN, EN ISO, ISO, GB, etc.

III. Applicable Medium

No.	ASHRAECode	MediumName	MolecularFormula or Structural Formula
1	R1336mzz-Z	trans-1,1,1,4,4,4-Hexafluoro-2-butene	CF₃CH=CHCF₃
2	R1234ze(Z)‌	cis-1,3,3,3-Tetrafluoropropene	CF₃-CH=CHF
3	R1243zf	3,3,3-Trifluoropropylene	‌CH₂=CF-CF₃
4	R1234ze(E)‌	trans-1,3,3,3-Tetrafluoropropene	CF₃-CH=CHF
5	R1234yf	2,3,3,3-Tetrafluoropropene	CF₃CF=CH₂
6	R1233zd(E)	trans-1-Chloro-3,3,3-trifluoropropene	CF₃CH=CHCl‌
7	R1270	propylene	CH₃-CH=CH₂
8	R1216	hexafluoro-2-butene	CF₃CF=CFCF₃
9	R245fa	pentafluoropropane	CF₃CH₂CHF₂
10	R600a	isobutane	(CH₃)₂CHCH₃
11	R515b	Refrigerant R515b
12	R514a	trans-1,1,1,4,4,4-Hexafluoro-2-butene	C₄H₂F₆
13	R513a	refrigerant R513a
14	R466a	refrigerant R466a
15	R455a	refrigerant R455a
16	R454c	refrigerant R454c
17	R454b	refrigerant R454b
18	R453a	refrigerant R453a
19	R452b	refrigerant R452b
20	R452a	refrigerant R452a
21	R450a	refrigerant R450a
22	R449a	refrigerant R449a
23	R448a	refrigerant R448a
24	R438a	refrigerant R438a
25	R-E170	dimethyl ether‌, ‌abbreviation:‌DME‌	CH₃OCH₃
26	R717	ammonia	NH₃
27	R601	n-pentane	CH₃(CH₂)₃CH₃
28	R600	n-butane	C4H10
29	R290	propane	C₃H₈
30	R161	ethyl fluoride	C₂H₅F
31	R32	difluoromethane	CH₂F₂
32	R507a	refrigerant R507a
33	R1113	chlorotrifluoroethylene	C₂F₃Cl
34	R236fa	hexafluoropropane	CF₃CH₂CF₃
35	R422e	refrigerant R422e
36	R422d	refrigerant R422d
37	R422a	refrigerant R422a
38	R417a	refrigerant R417a
39	R415b	refrigerant R415b
40	R415a	refrigerant R415a
41	R410a	refrigerant R410a
42	R409a	refrigerant R409a
43	R408a	refrigerant R408a
44	R407c	refrigerant R407c
45	R407a	refrigerant R407a
46	R406a	refrigerant R406a
47	R404a	refrigerant R404a
48	R402b	refrigerant R402b
49	R402a	refrigerant R402a
50	R401b	refrigerant R401b
51	R227e	heptafluoropropane	CF₃CHFCF₃
52	R152a	1,1-difluoroethane	CH₃CHF₂
53	R143a	1,1,1-trifluoroethane	CH₃CF₃
54	R142b	1-chloro-1,1-difluoroethane	CH₃CClF₂
55	R134a	1,1,1,2-tetrafluoroethane	CH₂FCF₃
56	R13B1	bromotrifluoromethane	CF₃Br
57	R12B1	bromochlorodifluoromethane	CF₂ClBr
58	R507	refrigerant R507
59	R502	refrigerant R502
60	R500	refrigerant R500
61	R452	refrigerant R452
62	R449	refrigerant R449
63	R417	refrigerant R417
64	R318	octafluorocyclobutane‌ or perfluorocyclobutane	C₄F₈‌
65	R218	octafluoropropane‌	C₃F₈
66	R160	chloroethane	C₂H₅Cl
67	R125	pentafluoroethane	CHF₂CF₃
68	R124	1-chloro-1,2,2,2-tetrafluoroethane	CHClFCF₃
69	R123	2,2-dichloro-1,1,1-trifluoroethane	CF₃CHCl₂
70	R115	chloropentafluoroethane	C₂F₅Cl
71	R114	dichlorotetrafluoroethane	C₂Cl₂F₄
72	R40	chloromethane	CH₃Cl
73	R23	trifluoromethane	CHF₃
74	R22	chlorodifluoromethane	CHClF₂
75	R21	dichlorofluoromethane	CHFCl₂
76	R12	dichlorodifluoromethane	CCl2F2
77	R11	trichlorofluoromethane	CCl₃F

Please click on the hyperlinks to view:

• Whatis special about KAIGEN and LEO's STEEL WELDED GAS CYLINDERS?

• Whatis special about KAIGEN and LEO's INDUSTRIAL NON-REFILLABLE WELDED CYLINDERS?

If you don't find the product or media you want, please contact our staff or leave us a message: Contact Us.
